Your Professional Related Consumables for Rotogravure Cylinder Machinery Supplier!



Since its establishment in 2010, Yuncheng Runto Gravure Machinery has focused on gravure platemaking machines, with its brand being Hongyuan Xinyu. We are a professional enterprise integrating the research and development, manufacturing, sales and after-sales service of gravure platemaking equipment. Our products include Rotogravure Cylinder Making Machinery, Fully Automatic Electroplating Line for Rotogravure, Fully Automatic Adapterless Electroplating Line, Gravure Cylinder Surface Processing Machinery, etc.


First 12 Last

Why Choose Us

Advanced Equipment

We have 5 drilling rigs, 2 sawing machines, 2 milling machines, 2 cranes and other cylinder production line equipment, which can efficiently support various production needs.





High-Quality Service

We always focus on providing professional and high-quality services to customers. We dispatch experienced after-sales service personnel to the site to assist customers in completing the installation and commissioning of the equipment to ensure the smooth operation of the equipment.

Professional Team

Our technical personnel account for 50%, of which 30% have college degree or above, and 20% have master degree or above. The team has solid professional knowledge and rich practical experience, and has built a high-quality and high-level technical support and after-sales service team.

Quality Control

We strictly implement the whole process quality management in accordance with national and industry standards, and implement standardized control in all links from raw material procurement to production and manufacturing, finished product inspection, etc. to ensure stableE and reliable product quality.



Our Best-Selling Related Consumables for Rotogravure Cylinder Machinery



Copper Grinding Stone for Gravure Grinding Machine
Copper grinding stone for gravure grinding machine are being mounted by hot-melt glue, is mainly used for rough-grinding and finishing grinding which can be used in various of rotogravure cylinder making copper polishing machine.


Electroplating Carbon Brush
Electroplating carbon brush used for gravure cylinder electropalting tank.It is used for conducting electricity for adaptor and plate rollers. It adopts spring design and has better conductivity.


Polishing Paste
Polishing paste for rotogravure copper polishing machine is conjunction with buffing cloth to copper surface of the gravure cylinder.No nick to the gravure cylinder.



Our Company Has More Products to Offer, Please Browse the Product Categories on the Website, If You Have Any Needs, Please Contact Us.



Copper Grinding Stone for Gravure Grinding Machine Specification



D.

200mm,etc

I.D.

100mm,50mm,etc

Thickness

50mm,70mm,etc

Grits

800#, 1000#, 2500#, 3000#, 6000#

Standard dimension

200*50*50,200*50*70,200*100*50,200*100*70(OD*ID*Thickness)



凹版滚筒粗糙度测试仪

Advantages of Copper Grinding Stone for Gravure Grinding Machine





High Precision

Copper grinding stones for gravure grinding machine are known for their fine structure and high precision. This makes them ideal for use in the gravure printing industry, where precise grinding and polishing are essential.

High Efficiency

Copper grinding stones for gravure grinding machine are also known for their high efficiency. They can grind and polish surfaces quickly and effectively, which is essential in an industry where time is money.

Mechanical Strength

Copper grinding stones for gravure grinding machine are made from high-quality materials that provide them with high mechanical strength. This means that they can withstand the high pressures and forces involved in the grinding and polishing process without breaking or cracking.

Adjustable Hardness

Copper grinding stones for gravure grinding machine can be made with adjustable hardness levels, which is an essential feature in the gravure printing industry. Different hardness levels are required for different materials, and copper grinding stones for gravure grinding machine can be made to meet these requirements.

Versatility

Copper grinding stones for gravure grinding machine can be made into various shapes to meet the requirements of different grinding and polishing applications. They can be used for rough-grinding, intermediate finishing, and finishing of brass and copper-plated rolls.



Instructions for Use of Copper Grinding Stone for Gravure Grinding Machine





1. After the copper grinding stone is unpacked, it should be bonded to the grinding disc in time to prevent the copper grinding stone from cracking and being difficult to bond due to long-term exposure.
2. The bonding temperature should not be too high. Wait until the adhesive is fully melted. The pressure should not be too high to prevent the copper grinding stone from deforming due to high temperature and pressure, affecting normal use. After the bonding is firm, cool it down with cold water immediately.
3. The copper grinding stone should not be removed for more than 24 hours. If it exceeds 24 hours, the copper grinding stone should be soaked in water in time to prevent the grinding stone from cracking and affecting normal use.
4. The angle of the grinding head of the grinder should be moderate, not too large, and the speed should not be too high.



Electroplating Carbon Brush Specifications



Material

Resistivity (μΩ·m)

Voltage drop for a pair brushes (V)

Coef of Friction (≤)

Wear volume for 50hrs (mm)

Rating Current density (A/cm2)

Allowable rim speed(m/s)

Metal graphite

0.115～0.345

0.30～0.70

0.2

0.4

20

20

Metal graphite

0.1～0.3

0.28～0.66

0.2

0.6

20

20

Metal graphite

0.23～0.68

0.36～0.95

0.2

0.3

15

25

Metal graphite

2.0～6.0

0.97～2.03

2

0.3

15

25

Silver graphite

1.05～3.15

0.05～1.62

0.2

0.25

15

35

Pure graphite

17～25

≤2.50(single）

0.27

1.50(100h)

10

70

Resin graphite

147～273

3.60～5.40

0.2

0.15

8

35

Electric graphite

22～36

1.95～3.25

0.25

0.15

10

40

Electric graphite

40～74

1.75～3.65

0.2

0.2

12

50

Electric graphite

40～74

1.82～3.78

0.2

0.2

12

50

Electric graphite

43～81

1.89～3.92

0.2

0.2

12

50

Electric graphtie

51

1.7

0.22

0.2

12.5

41




Advantages of Electroplating Carbon Brush

01/

Low Friction and Wear: Electroplating carbon brushes exhibit low friction levels due to the self-lubricating properties of carbon. This characteristic reduces wear and tear on both the brushes and the contacting surfaces, leading to longer lifespan and less frequent maintenance requirements.

02/

Good Conductivity: Carbon is an excellent conductor of electricity, ensuring efficient and consistent current transfer between moving and stationary parts. This high conductivity minimizes power loss, heat generation, and voltage drops, enhancing overall device performance.

03/

Thermal Resistance: Electroplating carbon brushes can withstand elevated temperatures generated during operation, making them suitable for applications involving high-speed and high-friction environments. Their ability to handle heat contributes to the durability and reliability of devices utilizing electroplating carbon brushes.

04/

Versatility: Electroplating carbon brushes can be customized to fit various applications. Manufacturers can modify the composition, shape, and size of the brushes to optimize their performance in different devices and operating conditions, allowing for adaptability and versatility.



Function of Electroplating Carbon Brush





Conducting Electricity

It ensures a continuous electrical connection between stationary and moving parts, crucial for electroplating equipment operation.



Ensuring Spark-Free Commutation

Electroplating carbon brushes play a vital role in maintaining efficient and safe operation by preventing sparking.



Material Composition

Typically made from carbon and graphite materials, electroplating carbon brushes are designed to be good conductors of electricity and durable, yet soft enough to prevent excessive wear on the contact surfaces.





Our Service





Assign a professional after-sales service personnel to arrive at the scene for guiding customers to install and debug, And we have full-time after-sales service personnel to follow up, understand and solve customer problems in the use of the company's products.Focus, professional, provide you with better service!



Packaging and Shipping



productcate-1-1



Our Certificate


productcate-1-1
productcate-1-1
productcate-1-1
productcate-1-1
productcate-1-1





Video







FAQ



Q: How to send my enquiry?

A: You can contact us by email, phone call, message (Whats APP, We Chat, Skype).

Q: Can you engineer come to our place to help with gravure cylinder making machine installation & commission?

A: Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.

Q: What is the package? Is it suitable for shipment?

A: Engravured cylinder Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation.

Q: Are you a factory or trading company?

A: We are a factory and we have professional team of workers , Designers and inspectors

Q: How about your after-sale service?

A: Our after sales support and service is second to none and we urgently respond to your queries, if parts are required they would be sent to you by international courier within 3 days.

As one of the most professional related consumables for rotogravure cylinder machinery manufacturers and suppliers in China, we're featured by quality products and good price. Please rest assured to buy related consumables for rotogravure cylinder machinery for sale here from our factory.

Exhaust Fan for chrome machine, Polishing Paste for Rotogravure Copper Polishing Machine, Sand Belt For Chrome Polishing Machine
